P&M Incorporated ) Pick up Cylinder lineup with rotate function

관리자 2022-10-31 17:12:41 Views 1,735

Greeting from P&M Incorporated.

This news letter contains rotary function implied pick up cylinder

for the best solution of handling small workpiece.

	Chapter 1 :	Pneuamtic Rotary Pickup Actuator - PPR & PPRL Series.
	Chapter 2 :	Motorized Rotary Pickup Actuator - PPRM Series.
	Chapter 3 :	Total product Catalogue - Ver. 2022 Released.

Cahter 1. Pneumatic Rotary Pickup Actoator

Affordable solution by compressed air only



[Direct link to details]
	Vacuum Suction Spring Cushion 2 - Position Rotation (90˚ or 180˚)	Vacuum Suction Spring Cushion 2 - Position Rotation (90˚ or 180˚) Up & Down stroke (10mm~30mm)

	High vacuum maintaining by direct piped vacuum rod Backlash free & high degree reliability by external stopping angle control Customized angle setting by customer requisition Customized vacuum pad connector application by customer requisition Auto switch for detecting rotation, Up & Down(PPRL only) detecting (Optional)

Application

	1) Realignment of workpiece from feeder for needs
	2) Adjustment of angle & direction of workpiece from tray to next process

* For Pitch Change application, please contact to office.

Chapter 2. Motorized Rotary Pickup Actuator

Freely angle control by motor application for rotary part

Rotary function with electrical motor
0˚~360˚ freely angle control
Precise degree of rotation with high resolution
Linear motion with guide cylinder inside

Connector Options

[Direct link to details]

Various motor

PAD Connector

Stepping + Encoder

(Standard)

· Direct to PAD
· Female screw type
· Male screw type
· One-Touch type
· Order-made service

· Affordable solution

· Close Loop control

Air Gripper

Servo Motor

(Optional)

Vacuum Suction
Spring Cushion
0˚ ~ 360˚ Rotation
Up & Down Stroke (10mm~30mm)

High rotate degree by direct vacuum rod
Encoder equipped stepping motor for Close-Loop system
Auto switch for Rotary and linear (Optional)
Economical solution with pneumatic type linear motion

· Operate at P or V
· 2,3,4 Jaw options
· Order-made service

· Powerful torque

· High speed control

· Close Loop control

* For application of Servo Motor, please contact to office.

Application

	1) Repositioning of disordered workpiece.
	2) Precise compensation of angle and position for workpiece

Random Position

PPRM & Vision

combination

Aligned position

Chapter 3. Total Product Catalogue Ver. 2022 Released

New version total product catalogue 2022 has been released

Catalogue (Book and PDF file) is free. If you need, please contact to below contacts.

E-mail : pnm@protec21.co.kr

PDF file download

office : +82-32-822-9183 (Dir. 1 - Busness dept)

We hope to meet valuable customer on the next news with more variaty and worthable news.

Your kind and warmful attention would be appreciated.

Thanks with best respects.

Moving toward the world with the best techonolgy!
